Hangers, Truss-outs and Advanced Scaffolding Systems

Scaffold hangers are engineered brackets fixed to existing structures (such as roof beams or structural steel) to support scaffold platforms where ground-based scaffolding cannot reach. Truss-outs are cantilever beams that extend scaffolding beyond the building line, providing access to overhangs, soffits, and areas outside the building footprint.

Yes, when properly designed and installed. All hanger and truss-out systems require structural engineer calculations, load testing of fixing points, and installation by CISRS Advanced qualified scaffolders. Every system is designed to TG20:21 standards with full documentation and method statements.

Roof overhang repairs, soffit and fascia work, chimney stack access, parapet wall maintenance, building facade work beyond the footprint, heritage conservation projects with restricted ground access, and any situation where standard scaffolding cannot reach the work area.

Truss-outs can typically extend up to 2.4m beyond the building line, depending on load requirements and structural fixing points. For longer reaches, multiple truss-outs or alternative cantilever configurations may be designed by our structural engineers.

All advanced scaffolding systems require comprehensive structural design including fixing point calculations, cantilever load analysis, and platform specifications. Designs must be certified by qualified engineers and include full documentation for site inspection and handover.

Yes. We regularly install hanger and truss-out systems on heritage properties throughout Sussex and Kent. Our engineers design non-invasive fixing methods that protect historic fabric while providing safe access. All work is documented for planning and conservation requirements.

Installation varies based on complexity and access requirements. Simple hanger installations may take 1-2 days, while complex multi-point truss-out configurations can require 3-5 days including load testing and certification.

Comprehensive safety systems include engineered fixing brackets, load-tested connections, guardrails and toe boards, fall arrest anchorage points, and regular competent person inspections throughout the hire period.

Our hanger and truss-out platforms are engineered for working loads from 250kg to 1,500kg depending on configuration and fixing point capacity. All platforms are designed to TG20:21 standards with appropriate safety factors for the specified use.

All installations include comprehensive documentation: structural engineer calculations, fixing point specifications, load capacity certificates, handover certificates, inspection schedules, and method statements covering installation and use.

Hanger and truss-out systems require installation by CISRS Advanced qualified scaffolders with specific training in cantilever and suspension systems. All fixing points must be certified by a structural engineer, and our teams hold full competency cards for complex scaffold configurations.
